EFS107.A0

Low Voltage Ceiling Sensor Kit

Product Documents

Features & Benefits

  • 12VDC input
  • PIR BT Sensor with Daylight Harvesting
  • Powered by power pack (PPA102Sx/PPA104Sx) and connected with a low voltage cable
  • Capable of ceiling mount with RC01 recessed ceiling adapter

Note: Lens sold separately

Specifications

Part Number

EFS107.A0

aaa

aaa

Component type

Sensor

bbb

bbb

Operating Temp

-30 to 55°C (-22°F to 131°F)

Technology

Bluetooth v4.2

Radio Frequency

2.4G Hz

Range

200ft

Input voltage

12V

Aux voltage

N/A

Control

Single 0-10V

Dimmability

0-10V

Ip rating

IP40

Color offering

White

Mounting options

Ceiling Mount

Mouting height

20ft

Sensor type

Daylight Harvesting, PIR

Warranty

5 year limited warranty

Certification

CE compliant, cULus Listed, DLC listed, FCC, RoHs, UL1376 Gold
