EFS104 Series

External Line Voltage High Bay Sensor

Features & Benefits



  • 120-277VAC input
  • Connects with 1/2″ standard knockout
  • Daylight Harvesting
  • BT PIR analog sensor with AlgoH™ algorithm to maximize detection without false trigger
  • Replaceable lens options



Note: Lens sold separately

Specifications

Part Number

EFS104.B1

aaa

aaa

Component Type

Sensor

bbb

bbb

Operating Temp

-30 to 55°C (-22°F to 131°F)

Technology

Bluetooth v5.0

Radio Frequency

2.4G Hz

Transmission Range

200FT

Input Voltage

120–277V

Aux Voltage

n-a

Control Output

Relay, Single 0–10V

Dimmability

0–10V

IP Rating

IP40

Color Offering

White

Mounting Options

Fixture Knockout (KO)

Mounting Height

40FT

Application

Indoor

Sensor Type

Daylighting, PIR

Warranty

5 year limited warranty

Certification

FCC Compliant, TAA Compliant, CE Compliant, cULus Listed, DLC Listed, RoHS Compliant, UL 1376 Gold
