Warehouse Lighting Controls
Estimated Total Savings: 20-60%
Nearly 66% of the utility spend in a warehouse can be attributed to lighting. By adding highbay sensors, you can be sure that all areas of your warehouse or manufacturing facility are always lit to the most appropriate levels, balancing both safety and savings. Lights can be virtually grouped to dim and switch on/off together. Each fixture is also individually addressable, allowing for the most flexibility and the most savings. Whether you own or lease your warehouse space, managing your facilities with Autani can reduce energy and maintenance costs, creating a more comfortable and secure operating environment for your customers and your employees.
Product Recommendations
EFS104.B1 External Line Voltage High Bay Sensor
- 120-277VAC input
- Connects with 1/2” standard knockout
- Daylight Harvesting
- Bluetooth PIR analog sensor with Algo2 algorithm to maximize detection without false trigger
- Replaceable lens options
- NOTE: Lens sold separately
IFS108-N.A0 Clip-Mount Panel Sensor
- Clip-mount allows sensor to attach to luminaire housing
- 12V sensor with oval shape is the ideal form factor for panels
- Bluetooth PIR analog sensor with Algo2 algorithm to maximize detection without false trigger
- Allows existing panel and downlight luminaires to upgrade to luminaire level lighting control (LLLC)
- Daylight Harvesting
WP1018A 8-Key Battery-Powered Bluetooth Wall Switch
- Quick push-button control of Keilton+autani devices via Bluetooth
- 4 separate scene buttons
- Powered by 2 x AAA batteries
- Approximately 5-8 years battery life
- Secure wall mount
- Can be linked to a light or group via app
WP1025A 5-Key Battery-Powered Bluetooth Wall Switch
- Quick push-button control of Keilton+autani devices via Bluetooth
- 3-scene programmable button
- Powered by 2 x AAA batteries
- Approximately 5-8 years battery life
- Secure wall mount
- Can be linked to a light or group via app
Control Strategies
Occupancy / Vacancy Sensing
Turn lights on when occupants are in a space and off when they vacate it. Alternate Functionality: Partial-on and manual-on modes are supported for additional savings and more stringent local codes.
High-End Trim / Institutional Tuning
Set the maximum light level based on customer requirements in each space to prevent overlighting.
Local Dimming Control
Permit occupants to lower the light below the high-end trim for comfort and additional savings.
Daylight Harvesting
Use dim lighting when daylight is available. Multiple zones are supported where required by code.
HVAC Control
Manage smart thermostats and sensors to implement temperature setback of HVAC equipment based upon occupancy or timeclock.
Plug Load Control
Manage control of select plug loads for Energy Code Compliance and the elimination of phantom loads when the building is not occupied.
Automatic Scheduling & Timeclock*
Automatically dim or shut off lighting based on centrally managed schedules.
* Requires Autani Manager or CR02-W.A0.
Demand Response*
Manage lighting and HVAC electrical loads to limit ratchet charges and peak demand pricing periods.
* Requires Autani Manager.
Business Outcomes
- Create immediate positive cash flow with energy savings.
- Enhance employee well-being.
- Prevent accidents.
- Lower maintenance cost.
- Maintain more effective temperature control to protect goods and improve productivity.
